RAM-30

	12' @ 400 Lbs.
	90° / 16 seconds
	Continuous Duty
	1/2 HP Motor
	120 VAC
	5.2 Amp
	50/60 Hz
	20"H X 13-1/2"L X 13-1/2"W
	75 Lbs.
	Knob Release

RAM-300

	18' @ 600 Lbs.
	90° / 14 seconds
	Continuous Duty
	1/2 HP Motor
	120 VAC
	4.5 AMP
	50/60 Hz
	27"H X 16-1/2"L X 20"W
	100 Lbs.
	Hand Lever Release

RAM-3000

	22' @ 800 Lbs.
	90° / 20 seconds
	Continuous Duty
	1/2 HP Motor
	120 VAC
	4.5 Amp
	50/60 Hz
	28-1/2"H X 18"L X 23"W
	110 Lbs.
	Hand Lever Release

RAM-30-30

	20' @ 3000 Lbs.
	90° / 16 seconds
	Continuous Duty
	3/4 or 1 HP Motor
	120 or 220 VAC
	4.5/8.5 Amp
	50/60 Hz
	27-1/2"H X 17-1/2"L X 23-1/2"W
	200 Lbs.
	Knob Release

RAM-3100 Maximum gate size and weight, 22' @ 1200 Lbs. Motor-3/4 HP, 120 VAC, 8.5 Amp.

RAM-3200 Maximum gate size and weight, 22' @ 1200 Lbs. Motor-1 HP, 220 VAC, 4.5 Amp.

ACCESSORIES COMMON TO GATE OPERATORS:

Loop Detector Photo Beam Radio Controls Magnetic Gate Lock
